2021 High quality Hot Wax Filling Machine - Push Type Heating Mixing Mascara Filling Machine – Eugeng Detail:

Model EGMF-02 with heating and mixing mascara filling machine is a  semi-automatic filling and capping machine design for the production of high viscous cosmetic liquid,such as lip gloss,mascara eyeliner,gel,cream,suitable for filling both liquid and high viscosity paste.Heating and mixing can turn on/off based on needs.


push heating mixing lip gloss filling machine


push type heating mixing lip gloss filling machine


heating mixing lip gloss filling machine tanks


heating mixing lip gloss filling machine tank


1

Lip gloss


2

Mascara


3

Eyeliner

· 1 set 30L pressure tank with inner plug for high viscosity materials

· Piston controlled dosing pump, and with servo motor driving , filling while tube moving down

. Machine with sucking back function so that prevent dripping

· Accuracy +/-0.5%

· Filling unit designed for easy strip-down cleaning and re-assembly to facilitate quick change over

· Servo-motor capping unit with adjusted torque,capping speed and capping height also adjustable

Touch screen control system with Mitsubishi brand PLC

Servo motor  Brand:Panasonic Original: Janpan

Servo motor control the capping , and torques can be adjusted , and reject rate is less than 1%

Heating mixing mascara filling machine wide application :

Widely used for filling high viscosity cosmetic liquid, cream, gel, lip gloss,mascara,eyeliner etc..

Heating mixing mascara filling machine puck customized

POM(according to the diameter of bottle)

Heating mixing mascara filling machine Capacity

30-35pcs/min

Model EGMF-02 with heater and mixer
Production type Push Pucks
Output capacity/hr 1800-2100pcs/h
Control type Servo motor&Air Cylinder
No.of Nozzle 1
Number of pucks 49
Vessel volume 30L/set
Display PLC
No.of operator 2-3
Power consumption 7.5kw
Dimension 1.5*0.8*1.9m
 Weight  450kg
 Air input  4-6kgf

1 (3)

Push table

1 (4)

Sensor for checking tubes no tube no filling

93

Filling nozzle with guider prevent nozzle broken

2

Two Pressure tanks with plug for high viscosity bulk with heated and mixer

1 (7)

Filling system fast cleaning and reassembly

1 (8)

Filling with servo motor driven, volume adjustable

1 (9)

Pressing wiper with cylinder,can turn on/off

104

Servo motor capping , torques can be adjustable

1 (11)

Capping head height can be easily adjusted

1 (12)

Different size tube just need change pucks

2

PLC MITSUBISHI

1

Servo Motor Panasonic

015

Pneumatic is SMC
