Herbal Balm Filling Machine
Herbal Balm Filling Machine Detail:
Model EGLF-06A Herbal balm filling machine is a full automatic lip balm filling line,used the production of lip balm and chapsticks,deodorant sticks etc.
Auto feeding empty balm tubes into puck holders
1 sets of 3 layers of 50L jacketed tank with heating and mixing functions
6 filling nozzles ,all parts contacting with bulk can be heated
Servo motor controlled dosing pump,piston filling system
Filling speed and volume adjustable easily on touch screen
Filling accuracy +/-0.5%
Piston filling system makes easy cleaning
Balm cooling under the room temperature with 3m conveyors belt
Reheating unit to make balm surface flat and more shinning with good looking
Automatic into cooling system, and cooling tunnel with 7 conveyors in and out
Frost moving system to prevent freezing and the frost moving cycle time can be adjust
Cooling temperature can be adjustable down to -20℃.
Danfoss refrigeration system and with water cooling cycle system for compressor.
Automatic feeding caps with vibrator
Slope conveyors belt pressing caps automatically
Gripping conveyors transport the goods back to automatic container feeding system
Herbal Balm Filling Machine Capacity
40 balms/min (6 filling nozzle)
Herbal balm filling machine Mold
Holder Pucks customized as different size
| Model | EGLF-06A |
| Production type | Liner type |
| Output capacity/hr | 2400pcs |
| Control type | Servo motor |
| No. Of nozzle | 6 |
| No. of pucks | 100 |
| Vessel volume | 50L/set |
| Display | PLC |
| No. of operator | 1 |
| Power consumption | 12kw |
| Dimension | 8.5*1.8*1.9m |
| Weight | 2500kgs |
| Air input | 4-6kgs |
auto feeding empty tubes
6 nozzles hot filling at the same time
auto loading empty tubes into puck holder
reheating to make surface flat
tunnel cooling machine
Product detail pictures:
